DYNEMEH RUBBER BUSH Series DLKI5 are highly effective And Compact Vibration damper for a variety of application of Anti Vibration Pad for machine Like-Compressors , pump,ID & FD fans ,motors,mahine tools , Gensets ,Air conditioners ,Labortory Equipment etc..
These Mounts anbe used for load appliations in both compression and shear.

Dynemech Rubber Bush are available in various standard and customized sizes. They are made from different types of rubber material and fabric reinforcement based in the application requirements.
Size :Dia-100(mm) To 165(mm)
Height-125(mm) To 60(mm)
Load Capacity (Kg.): 750 Kg/pc To 1400 Kg/pc
Natural Frequency (Hz): 7 To 8
Shore A Hardness: 70-75 To 80-85
Working Temp Range °C: (-16 To +90)
Material: Composite of Nitrile Rubber, Syntnetic Fibre and Cork Partices
Colour: Black And Green
04 Nos Weight is: 6 Kgs
Number Of Box:01
Box Dimension: 13"X8"X7"
Price @2760/-

DYNEMEH Anti-Vibration Pads RUBBER BUFFER Series are highly effective And Compact Vibration damper for a variety of application Like-Compressors , pump,ID & FD fans ,motors,mahine tools , Gensets ,Air conditioners ,Labortory Equipment etc..
These Mounts anbe used for load appliations in both compression and shear.

Dynemech Rubber Bush are available in various standard and customized sizes. They are made from different types of rubber material and fabric reinforcement based in the application requirements.
Outer Dia OD(mm):100mm To 165mm,
Inner Dia.ID(mm):100mm
Height-125(mm) To 60(mm)
Load Capacity (Kg.): 750 Kg/pc To 1400 Kg/pc
Natural Frequency (Hz): 7-8
Working Temp Range °C: (-16 To +90)
Shore A Hardness: 70-75 To 80-85
Material: Composite of Nitrile Rubber, Syntnetic Fibre and Cork Partices
Colour:Black And Green
04 Nos Weight is: 3 Kg
Number Of Box:01
Box Dimension:13"X8"X7"
Price @2240/-

Dynemech Insulating Dics for Anchoring Applications.
To be installed between the machine base and the nut to pravent transmission of the vibrations in to the foundation via bolt.

Dynemech Rubber Bush are available in various standard and customized sizes. They are made from different types of rubber material and fabric reinforcement based in the application requirements.
Anti-Vibration Pads

Size :Outer Dia OD(mm): 40mm To 75mm,
Inner Dia. ID(mm):17mm To 31mm
Height-25(mm) To 25(mm)
Load Capacity (Kg.): 95 Kg To 400 kg
Natural Frequency (Hz): 8
Shore A Hardness: 70-75
Working Temp Range °C: (-16 To +90)
Material:Composite of Nitrile Rubber, Syntnetic Fibre and Cork Particles.
Colour:Black And Green
04 Nos Weight is: 1 Kg
Number Of Box:01
Box Dimension: 5"X5"X5"
Price @340/-per piece

DYNEMEH RUBBER MOUNTS Series are highly effective And Compact Vibration damper for a variety of application Like-Compressors , pump,ID & FD fans ,motors,mahine tools , Gensets ,Air conditioners ,Labortory Equipment etc..
These Mounts anbe used for load appliations in both compression and shear.

Dynemech Rubber Bush are available in various standard and customized sizes. They are made from different types of rubber material and fabric reinforcement based in the application requirements.Size Outer Dia OD(mm):200mm To 220mm,
Inner Dia.ID(mm):68mm To 50mm
Height-175(mm) To 100(mm)
Load Capacity (Kg.): 9000 Kg/pc To 6000 Kg/pc
Natural Frequency (Hz): 7 To 7
Shore A Hardness: 80-85 To 70-75
Working Temp Range °C: (-16 To +90)
Material:Composite of Nitrile Rubber, Syntnetic Fibre and Cork Partices.
Colour:Black And Green
04 Nos Weight is: 20 Kgs
Number Of Box:01
Box Dimension: 13"X8X"7"
Price @3600/-

Dynemech Rubber Bush are available in various standard and customized sizes. They are made from different types of rubber material and fabric reinforcement based in the application requirements.Size :Dia-60(mm),
Inner Dia. :13.5(mm)
Height-50(mm)
Load Capacity (Kg.): 200 Kg/pc
Natural Frequency (Hz): 6
Shore a Hardness: 80-85
Working Temp Range °C: (-16 To +90)
Material:Composite of Nitrile Rubber, Syntnetic Fibre and Cork Particles.
Colour:Black And Green
04 Nos Weight is:1 Kg
Number Of Box:01
Box Dimension:5"X5"X5"
Price @300/-

Dynemech Rubber Bush are available in various standard and customized sizes. They are made from different types of rubber material and fabric reinforcement based in the application requirements.Outer Dia: 40mm To 75mm,
Inner Dia. ID(mm):17mm To 31mm
Height-25(mm) To 25(mm)
Load Capacity (Kg.): 95 Kg To 400 kg
Natural Frequency (Hz): 8
Shore A Hardness: 70-75
Working Temp Range °C: (-16 To +90)
Material:Composite of Nitrile Rubber, Syntnetic Fibre and Cork Particles
Colour:Black And Green
04 Nos Weight is: 1 Kg
Number Of Box:01
Box Dimension:5"X5"X5"
Price @410/-

DYNEMEH RUBBER BUSH Series are highly effective And Compact Vibration damper for a variety of application Like-Compressors , pump,ID & FD fans ,motors,mahine tools , Gensets ,Air conditioners ,Labortory Equipment etc..
These Mounts anbe used for load appliations in both compression and shear.

Dynemech Rubber Bush can be used in both Load Application Compression and Shear Both.
Inner Dia ID(mm):Dia:68mm To 50mm,
Size :Dia-200(mm) To 220(mm)
Height-175(mm) To 100(mm)
Load Capacity (Kg.): 9000 Kg/pc To 6000 Kg/pc
Natural Frequency (Hz): 7 To 7
Shore A Hardness: 80-85 To 70-75
Working Temp Range °C: (-16 To +90)
Material:Composite of Nitrile Rubber, Syntnetic Fibre and Cork Partices
Colour:Black And Green
04 Nos Weight is :25 Kg
Number Of Box:01
Box Dimension:13"X8"X7"
Price @5930/-

We are dealing in Insulating Discs for Machinery anchoring applications.
Anti Vibration Mounts / Mountings and Pads, Screw Support Mounts, Wedge Mounts, Vibration Insulation Plates, Spring Isolators, Rubber Air Springs, Machinery Raiser Damping Blocks, Rubber Sheet/Pads, Anti Vibration Pads, Anti Vibration Rubber Parts, Rubber And Rubber Metal Bonded Vibration Isolator, Spring Vibration Isolators, Anti Vibration Foundation Pads, Levelling Mounts, Cup Mount, Sandwich Pad, Machine Mounts, Cushyfoot Mountings, Shock And Vibration Isolators, To Foundation Isolation / Insulation.
Dynemech offers ANTI VIBRATION SHEETS made from high grade synthetic composite material.
Load Capacity (Kg)750OUTER DIAMETER OD (mm)100HEIGHT H (mm)125SHORE A HARDNESS70-75NATURAL FREQUENCY (Hz)7DEFLECTION UNDER LOAD (mm)18WORKING TEMPERATURE RANGE(◦C)-16 to 90

Dynemech Rubber Bush are available in various standard and customized sizes. They are made from different types of rubber material and fabric reinforcement based in the application requirements.
Outer Dia OD(mm):82mm,
Inner Dia. ID(mm):51mm
Height-105(mm)
Load Capacity (Kg.): 500 Kg/pc
Natural Frequency (Hz): 7
Shore A Hardness: 70-75
Working Temp Range °C: (-16 To 90)
Material:Neoprene
Colour:Black And Green
04 Nos Weight is: 6 Kg
Number Of Box:01
Box Dimension:13"X8"7"
Price @900/-per piece
